LOVOL M604, 60hp Cabin Tractor with Front End Loader

LOVOL M604, 60hp Cabin Tractor with Front End Loader

No review yet. Write Review
Regular Price $32,990.00

Product Type : Tractor

in stock SOLD OUT
Tannertrack Logo TYM & Lovol Tractors

LOVOL M604 60hp Tractor with 4in1 Front end Loader

In Stock NOW is our NEW Range of Lovol tractors ranging from 35-80hp. Come on down and inspect these top quality Tier 1 tractors. With their attention to detail from molded floor mats to very friendly joystick controlled front end loader and a top quality Gammer seat you can be sure you will be very happy in the new Gen-3 designed cabin with its heater/Aircon and very well insulated cabin. But it doesn’t stop there they have paired this long lasting and proven engine with a 12 speed synchromesh gearbox, rear remotes, dual element air cleaner and many more great features.

These quality in these tractors is outstanding and an inspection is a must!!

Call us now to find out more!!

Attachments available and in stock – Backhoes – Post Hole Diggers – Augers – Rippers – Slashers – Tow Bars – Bale Spears – Pallet Forks – Wood Chippers & More!!


Package Deals Available

Download Brochure Here



Drive type - on demand 4x4

Overall dimension(L * W * H) 4136*1870*(2822/2657)

Wheelbase (mm) 1990 Track(front/rear) 1250-1324/1200-1500 Track(front/rear) regulating method non-adjustable /step less Min.Ground clearance(mm) 310 Min.operating weight (with cab)(kg) 2525 Min.operating weight (without cab)(kg) 2320 Counterweight (rear) 270

Gears(forward/reverse) 12+12 Theoretical speed of each gear(forward/reverse) 2.37-38.46/2.07-33.71

Hydraulic system Hydraulic output flow (L/min) 40


Brand Xinchai Engine type 4-cylinder Intake mode naturally aspirated Number of cylinders 4 Bore 98 Stroke 105 Displacement(L) 3.168 Engine rated power kWrpm 35.3 Rated speed 2400 Type of air cleaner Dry Dual Element Type of cooling system Forced water-cooled Max. Torque revolving speed (rpm) 1861600~1800 Specific fuel consumption rate at rated conditions (g/kW.h) ?245 Fuel tank capacity (L) 65



Type of steering system Hydraulic Type of steering gear Orbit rotary valve type full-hydraulic steering gear Type of braking system wet disc mechanical control



Clutch type Dry Double action

Gearbox type Two-axis mechanical gearbox

Gearbox shift mode gear Synchronized shift Gearbox

Type of central transmission Spiral bevel gear type

Final transmission mode (rear) Planetary gear type



Tyre Type AG – R1a Radial Tyre Model (front/rear) 8.3-20/14.9-24



Type of linkage Three point rear linkage Linkage classes Cat. II Lift capacity(610mm point))kN 9.1 Regulating mode Draft and floating control



The number of PTO shaft splines 6 splines

 PTO shaft speed 540/760
